LOG SPLITTER VALVES
Nominal flow rate: 80 liter/min
Max. Pressure: P: 250 bar, T: 10 bar, A-B: 300 bar
Spool type: Standard open center spool (A spool)
Number of spools: From 1 to 8
Leakage: 20 cm3/min at 120 bar (From A,B to T)
Fluid temperature range: -10 oC … +80 oC
Working fluid: Mineral based hydraulic oil
Viscosity: 10-100 cSt (46 cSt mineral based hydraulic oil is recommended, may vary in different climates)
Filtration: 10 to NAS 1638
Nominal flow rate: 80 liter/min
Max. Pressure: P: 250 bar, T: 50 bar, A-B: 300 bar
Spool type: Standard open center spool (A spool)
Number of spools: From 1 to 6
Leakage: 18 cm3/min at 120 bar (From A,B to T)
Fluid temperature range: -10 oC … +80 oC
Working fluid: Mineral based hydraulic oil
Viscosity: 10-100 cSt (46 cSt mineral based hydraulic oil is recommended, may vary in different climates)
Filtration: 10 to NAS 1638
Nominal flow rate: 80 liter/min
Max. Pressure: P: 315 bar, T: 50 bar, A-B: 300 bar
Spool type: Standard open center spool, 4 positions
Number of spools: From 1 to 6
Leakage: 6 cm3/min at 100 bar (From A,B to T)
Fluid temperature range: -10 oC … +80 oC
Working fluid: Mineral based hydraulic oil
Viscosity: 10-100 cSt (46 cSt mineral based hydraulic oil is recommended, may vary in different climates)
Filtration: 10 to NAS 1638
